MB GA H110M-DS/2

-Supports 6th Generation Intel Core Processor
-Dual Channel DDR4, 2 DIMMs
-8-channel HD Audio with High Quality Audio Capacitors
-Audio Noise Guard with LED Trace Path Lighting
-Realtek GbE LAN with cFosSpeed Internet Accelerator Software
-All new GIGABYTE APP Center, simple and easy use
-GIGABYTE UEFI DualBIOS Technology
-Support Intel Small Business Basics


CPU
-Support for Intel Core i7 processors/Intel Core i5 processors/Intel -Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package
-L3 cache varies with CPU
(Please refer "CPU Support List" for more information.)

Chipset
-Intel H110 Express Chipset

Memory
-2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
-Dual channel memory architecture
-Support for DDR4 2133 MHz memory modules
-Support for ECC UDIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
-Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modules
(Please refer "Memory Support List" for more information.)

Onboard Graphics
-Integrated Graphics Processor - Intel HD Graphics support:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
-Maximum shared memory of 512 MB

Audio
-Realtek ALC887 codec
-High Definition Audio
-2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
-Support for S/PDIF Out
